6
Ports:
DC 5V: Connecting to AC adapter
WAN1~4 Port: Four RJ-45 type WAN ports connecting to broadband transmission equipment such as ADSL
or Cable modem via RJ-45 cable.
LAN 1~8 Port: Eight RJ-45 type LAN port connecting to your network devices such as Hub/Switch via RJ-45
cable.
DMZ Port: One RJ-45 type DMZ port connecting to your network devices. It can also be configured as the 5 th
WAN port via software.
Factory Reset: Press Factory Reset button can be defined as to reload factory default value or reset back to
latest configuration by software. When you finish defining the Default Button Option, just pressing Factory
Reset button 2 seconds and releasing it, the router will load the default settings or back to latest configuration.
1.3 Packing List
z IGR-2500 Five-WAN Internet Gateway
z Installation CD-ROM
z Quick Installation Guide
z CAT-5 UTP Fast Ethernet cable
z AC Adapter
When you open your package, make sure all of the above items are included and not damaged. If you
see that any components are damaged, please notify your dealer immediately.
