AirLive ES-4000 v2 User Manual

Page 13

Step4.

Select the language and character encoding. (Figure 2-3)

Figure 2-3 Select the language and character encoding

When system can not identify the data character encoding that is going to be saved into database, it

will use the default setting.

Step5.

Go to System ( Interface, enter the following setting: (Figure 2-4)

Provide a valid IP address of the LAN subnet along with its mask, default gateway and DNS

sever address.

Figure 2-4 Interface setting

Please refer to LAN segment setting to set up interface address. For example, if the LAN segment is

172.16.X.X, then any changes made must be within the same segment in order to take effect.

The following table lists the standard virtual IP range, all external real IPs are forbidden.

10.0.0.0 ~ 10.255.255.255

172.16.0.0 ~ 172.31.255.255

192.168.0.0 ~ 192.168.255.255
