AirLive CU-720PIR - Manual (Page 8)

1. Introduction
3 AirLive CU-720PIR User’s Manual
1.4 Package Contents
A user can find the following items in the package:
z This camera is the main element of the product.
z Camera Stand with screws
z A/V Cable is for audio line output (white cable) and video output (yellow cable). Note
that this cable is optional.
z Power adapter dedicates 12V DC electric power output to Network Camera.
z User’s manual CD provides important information and instructions for operating the
Network Camera.
z Quick start guide provides important information and instructions for installing this
device.
If any of the above items are missing, please contact your dealer immediately.
Note: Using a power supply with a different voltage than the one included with the Network
Camera will cause damage and void the warranty for this product.
1.5 Physical Description
1.5.1 Front View
1. IR LEDs
These IR LEDs are very useful for low-lux environment to provide extra light source for
image sensor.
