[Multicast]
IGMP (Internet Group Multicast Protocol): It is a session-layer protocol used to establish membership in a
multicast group. The ADSL supports both IGMP version IGMP-v1 & IGMP-v2. Select None to disable it.
Note: Every time you change one setting, you must click SAVE button once, and then go to next
setting’s change.
4.3.2 LAN
There are the IP settings of the LAN Interface for the device. These settings may be referred to as
Private settings. You may change the LAN IP address if needed. The LAN IP address is provided to your
internal network and cannot be seen on the Internet.
[Router Local IP]
IP Address: Enter the IP address of your ADSL router in dotted decimal notation, for example,
192.168.2.1 (default setting).
IP Subnet Mask: Your ADSL router will automatically calculate the subnet mask based on the IP address
that you assign. Unless you are implementing sub netting, use the subnet mask computed by the ADSL
router.
Dynamic Route: Select the Dynamic Route from RIP1, RIP2-B, and RIP2-M. Please refer to Internet 
Dynamic Route. The only difference is the interface.
Direction: Select the RIP direction from None, Both, In Only and Out Only.
