CHAPTER 12 EXPANSION
38 39
MXL2
To transmit track information to MXL2
Select tracks to be submitted by clicking on
the square check box or on the name of the
track.
Drag in the right panel or press button
The tracks’ information is updated in the
SmartyCam panel.
To receive track information from MXL2
Select tracks to be submitted by clicking on
the square check box or on the name of the
track.
Drag in the left panel or press button
Tracks’ information is updated in the PC list.
Lambda Controller
Memory Module
Channel Expansion
GPS05 Module
ECU
SmartyCam HD GP
8 Analog Inputs
4 Speed Inputs
Modular Data Acquisition System
Using our built in CAN bus, add expansion modules like GPS, external memory modules, channel
expansions, lambda controllers. These are only some of the items that can be added to our
MXL2 range for incrementing the performance and the data acquired.
CHAPTER 11 GPS
12. Expansion
