- 15 -
SERVICE PARTS
KEY PART QTY (HOOD WIDTH)
NO. NUMBER DESCRIPTION 42’’ 54’’
1 V08069 C ONTROL P ROCESSOR U NIT 1 1
2 V08073 P ARTICULATES S ENSOR 1 1
3 V13924 M ALE C ONNECTOR 1 1
4 V13923 F EMALE C ONNECTOR 1 1
5 V08074 C ONTROL I NTERFACE 1 1
6 V16569 L AMP S HELL , S OCKET AND T RIM A SS ’ Y 4 6
7 V05921 H ALOGEN B ULBS (50 W, 120 V, PAR16, GU-10) 4 6
8
V16967 E VOLUTIONARY ™ H YBRID B AFFLE F ILTER 8.95” X 8.61” X 1” ( INCL . ITEM 10) 2 -
V16968 E VOLUTIONARY ™ H YBRID B AFFLE F ILTER 14.95” X 8.61” X 1” ( INCL . ITEM 10) 1 3
9 V05528 F ILTER S PRING C LIP 3 3
10
V07694 S ECONDARY M ICROMESH F ILTER 8.84” X 8.50” 2 -
V07695 S ECONDARY M ICROMESH F ILTER 14.84” X 8.50” 1 3
11
V16794 G REASE D RIP R AIL 36” 1 -
V16796 G REASE D RIP R AIL 48” - 1
12 V17448 I NSIDE F RAME A SS ’ Y (42”) ( INCLUDING ITEM 9) 1 -
V17449 I NSIDE F RAME A SS ’ Y (54”) ( INCLUDING ITEM 9) - 1
* V03435 T HERMISTOR H EAT S ENTRY 1 1
* V08072 I NSTALLATION G UIDE 1 1
P ARTS B AG (S TEEL WOOD SCREW NO . 10 X 1.5’’ [10],
1 1
*
V08068
S CREWS NO . 8 X 3/8’’ [6], S TEEL WASHERS NO . 10 [10])
* V05869 B EST BY B ROAN L OGO 1 1
* N OT SHOWN .
* N OT SHOWN .
IP29M S
ERIES
HL0094
1
7
3
2
4
5
8
9
6
10
11
12
KEY PART QTY
NO. NUMBER DESCRIPTION DECORATIVE FLUE DRY WALL TRIM
A CCESSORY P ARTS B AG (S TEEL HEXAGONAL LOCK - NUT [5],
* V06927 S CREWS NO . 8 X 3/8’’ [14], S TEEL WASHERS NO . 10 [10] 1 1
S TEEL WOOD SCREW NO . 10 X 1.5’’ [10])
