5.7 DVI
I
NTERFACE
The DVI Interface is used to transfer analog and digital video signals. A DVI-I Cable is
required to connect a digital display to the device. It is also possible to connect a VGA
display by using a suitable DVI-VGA adapter.
Notice:
The DVI Interface is a Single Link Interface. The video signals are transferred analog and
digital.
PIN-NUMMER
SIGNAL NAME
1
TMDS Data2-
2
TMDS Data2+
3
TMDS Data2/4 Shield
4
N/C
5
N/C
6
DDC Clock [SCL]
7
DDC Data [SDA]
8
Analog vertical sync
9
TMDS Data1-
10
TMDS Data1+
11
TMDS Data1/3 Shield
12
N/C
13
N/C
14
+5V Power
15
Ground (for +5V)
16
Hot Plug Detect
17
TMDS Data0-
18
TMDS Data0+
19
TMDS Data0/5 Shield
20
N/C
21
N/C
22
TMDS Clock Shield
23
TMDS Clock+
24
TMDS Clock-
C1
Analog Red
C2
Analog Green
C3
Analog Blue
C4
Analog Horizontal Sync
C5
Analog GND Return: (analog R,
G, B)
