Industrial PCs OPC7013/7015/7022

NSTALLATION

3.1

NSTALLATION OPTION

This device is intended for integration into switch panels or switching cabinets. In order to
allow for a safe installation and operation (connector access), these switch panels or

control desks must be accessible from the back. The device can be integrated into
switching cabinets with a wall thickness of 2 to 13 mm. We recommend a minimum of 3

mm for correct installation with an IP65 front protection class.

Warning:

To avoid overheating in operation: The device must not be exposed to direct radiation by

sunlight or any other light or heat source.
If the device is integrated in a panel, casing or similar enclosures, you must ensure that

no heat accumulation builds up. The maximum permissible environmental temperature

must never be exceeded.
Devices including a data drive must only perpendicularly be integrated. Any deviation

must be agreed with ads-tec.
The IP65 protection class is only achieved after correct installation.

Note:
When selecting the enclosure for integration, the power dissipation total of the system

including that of all integrated PCBs must be taken into account. The enclosure must be

calculated in such a way that the maximum environmental temperature is not exceeded in

any case.
