5.4 Check of Readiness for Operation

Check the device for any hidden damage caused by improper transport, improper operating or storage
conditions or by improper use (e.g. smoke development from the device, etc.). Immediately shut down the
device and prevent any further accidental commissioning if any damage is detected.

os: 21 /Datentechnik/Bedienung/Softkeyboard/Softkeyboard für VMT 60xx @ 1\mod_1228750145198_6.doc @ 4251 @

Pos: 22 /Datentechnik/Bedienung/Touch Screen/Touch Screen für VMT 60xx @ 1\mod_1246361069977_6.doc @ 5853 @

5.5 Status Indicators

SYS‐LED (Bicoloured)

Depending on the colour and type of flashing, different device states are displayed by the SYS LED.

The following signals are displayed:

 LED lights green

The device is ready for operation (Power ON).

 LED is off

The device is switched off. (Power OFF)
