Debris Loader Owner’s Manual

21

Section

SPECIFICATIONS

7

DL12670

DL12725

DL10570

DL8390

Flex Hose Size

12" dia. x 10'

12" dia. x 6-1/4'

10" dia. x 12.5'

8" dia. x 12.5'

Rotor Size

19.88" x 7"

19.88" x 5.44"

16.25" x 6.13"

16.25" x 6.13"

Discharge Tube

Size

8" dia.

8" dia.

8" dia.

8" dia.

Max CFM

(cubic ft/min)

3275

3597

2317

2317

Chute Rotation

360 degrees

360 degrees

360 degrees

360 degrees

Hose Length (ft)

12

6

12

12

Drive Type

Belt

Shaft

Shaft

Shaft

Starter Type

Electric

Electric

Recoil

Recoil

Belt Size

2B70

N/A

N/A

N/A

Weight (lbs.)

1022 lbs.

850 lbs.

280 lbs.

280 lbs.

Tires

P215/70R15

P215/70R15

N/A

N/A

Mounting Type

2" Ball Coupler

2" Ball Coupler

Receiver Hitch

Receiver Hitch

Engine

Honda 670cc

gasoline

Kohler 725cc

gasoline

Briggs & Stratton

Vanguard 570cc

gasoline

Honda 390cc

gasoline

Specifications are subject to change due to design modifications.

7.1 DEBRIS LOADER SPECIFICATIONS

DL12670 OPTIONS

KIT

PART NUMBER

16" VERTICAL CHUTE

EXTENSION KIT

75888-00

4' FLEXIBLE HORIZONTAL

CHUTE EXTENSION KIT

74737-00

ABRASION RESISTANT STEEL

WEAR PLATE KIT

74773-00

DL12725 OPTIONS

KIT

PART NUMBER

PINTLE HITCH KIT

14900-00

WORK LIGHT KIT

75754-00

TOOL HOLDER KIT

75761-00

WEAR LINER REPLACEMENT KIT

75767-00

DL8390 AND DL10570 OPTIONS

KIT

PART NUMBER

WEAR LINER REPLACEMENT

KIT

75768-00

WORK LIGHT KIT

75754-00

7.2 OPTIONS AVAILABLE FOR DEBRIS LOADERS
