Page 12
12 INCH CHIPPER
8
Section
FEATURES & CONTROLS
DISCHARGE
CAP
DISCHARGE
CHUTE
ENGAGEMENT
HANDLE
FEED ROLLER
LOCK UP PIN
KNIFE ACCESS
COVER LOCK
PIN
HITCH
KNIFE
ACCESS
COVER
FEED ROLLER
CONTROL BAR
3
Feed Roller Controls
Control Panel
FEED ROLLER
LIFT CONTROL
FEED ROLLER
SPEED CONTROL
Understanding how your machine works will help you achieve the best results when using your machine. The following
descriptions defi ne the features and controls of your machine.
