12 INCH CHIPPER 6
Section
ASSEMBLY
There are two oil filler caps (see below). Either can be used
to add oil.
2
2.2 ADD MOTOR OIL
Oil Filler Cap
Other oil filler cap and dipstick
Check the oil level and, if needed, fi ll the engine crankcase
with the type and amount of oil specifi ed in the engine
owner’s manual.
2.1 INSTALL A BATTERY
You will need to purchase a battery. Choose a battery that
meets or exceeds the following specifi cations:
Nominal Voltage: 12 Volt
CCA: 925 with 1050 reserve capacity
Type: Exide Group 31
HP 31E (SAE Post Term)
To install the battery:
BATTERY
BOX
Locate the battery box (shown below). 1.
Remove the cover of the battery box and set the battery 2.
inside.
Hook up the battery by connecting the red wire to the 3.
positive terminal and the black wire to the negative
terminal.
Reattach battery box cover. 4.
Tools can also be stored in the extra space of the battery
box. The tools should be secured in their own container.
