29 6 INCH CHIPPER
ENGLISH
Section
7.1 SPECIAL TORQUE REQUIREMENTS
SPECIAL TORQUE REQUIREMENTS
LOCATION ON MACHINE HARDWARE DESCRIPTION TORQUE (UNIFIED INCH)
ON CHIPPER DISK, BLADE MOUNTING CAP
SCREWS
M16 X 2.0 X 30 HEX HD W/
PATCH
120 FT-LBS
SPECIFICATIONS
7
CH611DH
DESCRIPTION English Metric
OVERALL SIZE 143” x 59” x 93” 363x150x236cm
OVERALL WEIGHT 2300 lbs. 1,043 kg
MAX CHIPPER CAPACITY 6” dia. 15.2 cm
CHIPPER BLADES
4 reversible
4" X 5.1" X 0.38"
10.2 X 13.0 X 1.0 CM
CHIPPING ANVIL 4-edge adjustable 4-edge adjustable
DISC SPEED 1700 RPM 1700 RPM
DISC SIZE 26” dia. 66 cm
DISC WEIGHT 165 lbs. 75 kg
DISCHARGE TUBE SIZE 6.7” 17 cm
DISCHARGE TUBE HEIGHT 93” 236 cm
DRIVE TYPE belt belt
DRIVE BELT SIZE triple banded 3RB48 triple banded 3RB48
TIRE SIZE P215/75R15 P215/75R15
JACK 800 lb. rating 363 kg
ENGINE
Kubota 1.1 L
Diesel, model # 1105B-1
Kubota 1.1 L
Diesel, model # 1105B-1
FUEL TANK CAPACITY 18 gal. 68 L
HYDRAULIC FEED RATE 0-125 ft/min 0-38m/min
HYDRAULIC OIL TANK
CAPACITY
3 gal. 11.3 L
