IOGear GCE800W6 User Manual
Page 18
19
18
5. Connect the cables from the remote console devices to their ports on the rear panel of the remote unit
(CE800R).
6. Connect one of the power adapters (provided) to an AC source; connect the adapter’s power cable to
the Power Jack on the CE800L.
7. Connect the other power adapter (provided)to an AC source; connect the adapter’s power cable to the
Power Jack on the CE800R.
CE-800L
CE-800R
CE-800L
6
1
4
2
3
5
7
