IOGear GCE800W6 User Manual
Page 12
12
13
No.
Component
Description
1
USB Peripheral Port
External USB Mass Storage compliant flash drives plug into this port.
2
Picture Compensation
Switches
These switches adjust the picture quality of the remote console. See Picture
Compensation, page 12 for details.
3
Picture Compensation
LED
Flashes to indicate that picture quality has been
adjusted. See Picture Compensation, page 12 for details.
4
Operating Mode
Selection Switch
Pressing this switch toggles the operating mode between Auto and Remote.
See Mode Selection, page 11 for details.
5
Remote LED
The Remote LED indicates the operating status of the Remote unit (see
CE800R (Remote Unit):, page 13, for details).
6
Link LED
Lights to indicate that the CE800R is connected to the CE800L
