IOGear GCE800W6 User Manual
Page 10
10
11
No.
Component
Description
1
KVM Port Section
This section is made up of a microphone jack, speaker
jack and KVM (keyboard, video, mouse), data connector.
The cable that links the CE800L to your local KVM
console plugs in here. Only KVM cables designed to work with this switch can be
used.
2
Audio connections
microphone and speakers connect here
3
USB Port
External USB Mass Storage compliant flash drives plug
into this port..
4
Operating Mode
Selection Switch
Pressing this switch toggles the operating mode between
Auto and Local. See Mode Selection, page 11 for details
5
Remote LED
The Local Unit has two LEDs to indicate the operating
status of the Local and Remote units (see LED Display,
page 12 for details).
6
Local LED
