SECTION 2 - PROCEDURES

2-42

– JLG Lift –

3120864

MEASURING POINT

MEASURING POINT

FORWARD

a. BOOM FULLY ELEVATED

AND FULLY RETRACTED

b. BOOM AT HORIZONTAL

AND FULLY EXTENDED

Figure 2-16. Swing Bearing Tolerance Boom Placement

MEASURING POINT

TURNTABLE REF.

FRAME REF.

SWING BEARING

Figure 2-17. Swing Bearing Tolerance Measuring Point
