SECTION 1 - SPECIFICATIONS
3120864 – JLG Lift – 1-9
1.8 BOOM TAPE
100HX Dual Capacity.
Blue - Not used.
Yellow - 157.5 cm.
Red - 228.6 cm.
White- 299.7 cm.
110HX Single Capacity.
Blue - Not used.
Yellow - Not used.
Red - 311.2 cm.
White - 400.1 cm.
110HX Dual Capacity.
Blue - Not used.
Yellow - 217.2 cm.
Red - 311.2 cm.
White - 400.1 cm.
100HX+10.
Blue - 134.6 cm.
Yellow - Not used.
Red - 221.0 cm.
White - 351.8 cm.
1.9 MAJOR COMPONENT WEIGHTS
1.10 SERIAL NUMBER LOCATIONS
For machine identification, a serial number plate is affixed
to the left side of the frame, below the battery compart-
ment. If the serial number plate is damaged or missing,
the machine serial number is stamped on the left side of
the frame between the front and rear wheels, below the
turntable bearing and on the right side of the turntable in
the bottom of the valve compartment. In addition, the last
five digits of the serial number are stamped on top of the
fly end of the base boom section.
1.11 CRITICAL STABILITY WEIGHTS
DO NOT REPLACE ITEMS CRITICAL TO STABILITY, SUCH AS THE
COUNTERWEIGHT OR FOAM-FILLED TIRES, WITH ITEMS OF DIF-
FERENT WEIGHT OR SPECIFICATION. DO NOT MODIFY UNIT IN
ANY WAY TO AFFECT STABILITY.
NOTE: All weights listed below are in Kg.
Table 1-10.Major Component Weights
Component KG.
Platform (36x48) w/o Control Box 68
Platform (36x60) w/o Control Box 75
Platform (36x72) w/o Control Box 82
Platform (36x96) w/o Control Box 100
Boom - 100HX (Incl. Lift Cylinder) 4.500
Boom - 110HX (Incl. Lift Cylinder) 4,971
Boom - 100HX+10 (Incl. Lift Cylinder) 4,844
Turntable (w/Ford Engine, Less Cwt.) 4,672
Turntable (w/Deutz Engine, Less Cwt.) 4,817
Turntable (w/Cummins Engine, Less Cwt.) 4,742
Frame Complete (incl. Wheels and Tires) 6,178
Complete Machine - 100HX 16,783
Complete Machine - 110HX 18,371
Complete Machine - 100HX+10 17,464
Table 1-11.Critical Stability Weights
Component 100HX 110HX 100HX+10
Counterweight
(1.5:1) 2790 4695 4468
Counterweight
(2:1) N/A 4695 4468
Foam-Filled Tires
(each) 318 318 318
Ford Engine 238 238 238
Deutz Engine 380 380 380
Cummins Engine 308 308 308
36x48 Platform N/A N/A 68
36x60 Platform N/A N/A 75
36x72 Platform N/A N/A 82
36x96 Platform 100 100 100
