SECTION 1 - SPECIFICATIONS
1-2 – JLG Lift – 3120864
Turning Radius
Outside - 7.1 m w/axles extended.
Boom Speed
Extend - 128-156 Seconds.
Retract - 93-113 Seconds.
Lift Up - 65-80 Seconds
Lift Down - 52-64 Seconds.
Swing Speed
360° - 260-350 Seconds.
Boom Elevation
Models 100HX/110HX.
+75° (above horizontal) to -21° (below horizontal).
Model 100HX+10 (110HXER).
Main Boom - +75° (above horizontal) to -21° (below
horizontal).
Extend-a-Reach - +15° (above horizontal) to -80°
(below horizontal).
Machine Weight
100HX - 16,511 kg.
110HX - 18,330 kg.
100HX+10 (110HXER) - 18,001 kg.
Machine Stowed Height
3.0 m.
Machine Stowed Length
100HX - 11.0 m
110HX - 11.8 m
100HX+10 (110HXER) - 13.5 m
Machine Width
With axles retracted - 2.6 m.
With axles extended - 3.3 m.
Wheelbase
3.4 m
Maximum Tire Loads
1.4 TORQUE REQUIREMENTS
NOTE: See Procedure Section for tightening sequence of
turntable bearing bolts.
NOTE: When maintenance becomes necessary or a fas-
tener has loosened, refer to the Torque Chart to
determine proper torque value.
Table 1-1.Maximum Tire Loads
Max. Load Max Bearing Pressure
Description Kg kg/cm 2
100HX 9027 10
100HX+10 10769 11.8
110HX 9771 10.7
Table 1-2.Torque Requirements
Description Torque Value Interval Hours
Bearing to Chassis 298 Nm 50/600*
Bearing to Turntable 298 Nm 50/600*
Wheel Lugs 407 Nm 100
Turntable Springs 102 200
Boom Chains 80 500
Platform Rotator Bolt 190 500
* Check swing bearing bolts for security after first
50 hours of operation and every 600 hours thereaf-
ter.
