SECTION 1 - SPECIFICATIONS
3120271 – JLG Lift – 1-13
1.10 CRITICAL STABILITY WEIGHTS 1.11 SERIAL NUMBER LOCATION
A serial number plate is affixed to the left rear front of the
turntable. If the serial number plate is damaged or miss-
ing, the machine serial number is stamped on the left side
of the frame between front and rear wheels, below turnta-
ble bearing. In addition, the last five digits of the serial
number are stamped on top of the fly, mid and base end
of the boom and on the left side of the turntable.
Table 1-9. Critical Stability Weights
Component Lb.s KG.
Engines Deutz F4L912 837 380
Ford LRG 423 410 186
Cummins 4B3.9 680 309
Tire & Wheels 15x19.5 Tire 130 59
Wheel 72 33
Foam Fill 320 145
Figure 1-2. Serial Number Locations
