SECTION 1 - SPECIFICATIONS
1-12 – JLG Lift – 3120271
Lift Down - 1500 psi (103 Bar)
Swing - 1500 psi (103 Bar).
Telescope In - 3000 psi (207 Bar) Prop. Tele 3750 psi
(259 Bar).
Tele Out - 1500 psi (103 Bar).
Solenoid Main Relief - 3100 psi (214 Bar)
2 Wheel Steer - 1500 psi (103 Bar)
2 Wheel Steer w/4WD - 1500 psi (103 Bar).
4 Wheel Steer; Axle Lift Cyl. - 2200 psi (152 Bar).
Extend-A-Reach Up - 2500 psi (172 Bar)
Extend-A-Reach Down - 1100 psi (76 Bar)
NOTE: Refer to Section 2 for pressure setting procedures.
1.7 MAJOR COMPONENTS WEIGHTS
1.8 CYLINDER SPECIFICATIONS
1.9 BOOM TAPE
American Standard
Red - 39 in. (99 cm).
Yellow - 34 in. (86.4 cm).
Blue - 193.9 in. (492.5 cm).
Canadian Standard
Red - 53 in. (134.6 cm).
Yellow - 42 in. (106.7 cm).
Blue - 171.8 in. (436.4 cm).
Table 1-7. Major Component Weights
Component Lbs. KG.
Platform w/o Control Box 236 107
Boom (includes Lift Cylinder, Rotator, and Sup-
port) 4816 2184
Turntable Complete (includes Engine) 14972 6790
Frame Complete (includes Tires and Wheels) 9290 4213
Complete Machine - 2WD No Options 28605 1297
3
Complete Machine - 4WD No Options 29106 1320
0
Complete Machine (80HX+6) 2WD No Options 31856 1444
7
Table 1-8. Cylinder Specifications
DESCRIPTION BORE STROKE ROD DIA.
Master Level 2.50 15.25 1.25
Slave Level 2.50 15.21 1.25
Lift 8.00 30.75 3.50
Lockout
(Oscillating Axle)
4.00 4.88 1.25
Lockout
(4WD)
4.00 4.25 1.25
Telescope 3.50 257.9 2.50
Steer (2WD) 3.00 8.06 1.25
Steer (4WD) 3.00 9.81 1.50
Extend-A-Reach
Lift 3.00 12.687 2.00
Slave 3.50 7.25 1.75
