SECTION 1 - SPECIFICATIONS
3120271 – JLG Lift – 1-9
Ford Engines
Single Viscosity Oils (SF, SF-SE, SF-CC, SF-CD).
Multi-Viscosity Oils (SF, SF-SE, SF-CC, SF-CD).
* Not recommended for severe service - includ-
ing high RPM operation.
Deutz F4L912 Engine
Single Viscosity Oils (CD-SE, CD-SF).
Multi-Viscosity Oils (CD-SE, CD-SF).
* This viscosity can be used at colder temperatures only
with engine oil preheating.
Wisconsin V465D Engine
Single Viscosity Oils (MS, SD, SE).
Multi-Viscosity Oils (MS, SD, SE).
NOTE: Crankcase oil should meet one of the following API
classification grades: SE/CC, SE/CD, SF/CC, SF/
CD.
Cummins 4B 3.9C
Multiple Viscosity Oils (CE/SG).
.
When Outside Temp
is Consistently
Use SAE
Viscosity Number
-10° F - +60° F. *10W
+10° F - + 90° F. 20W-20
Above +32° F. 30
Above + 50° F. 40
When Outside Temp
is Consistently
Use SAE
Viscosity Number
Below +10° F. *5W-20
Below +60° F. 5W-30
-10° F - +90° F. 10W-30
Above -10° F. 10W-40 or
10W-50
Above +20° F. 20W-40 or
20W-50
When Outside Temp
is Consistently
Use SAE
Viscosity Number
-20° F - +25° F. *10W
+15° F - + 50° F. 20W-20
+40° F - + 85° F. 30
Above 75° F. 40
When Outside Temp
is Consistently
Use SAE
Viscosity Number
-40° F - +75° F. *5W-20
(Synthetic)
-5° F - +70° F. 10W-30
-5° F - +85° F. 10W-40
+15° F - +75° F. 15W-30
Above +15° F. 15W-40
When Outside Temp
is Consistently
Use SAE
Viscosity Number
+15° F - 0° F. *10W
+40° F - + 15° F. 20-20W
+120° F - + 40° F. 30
When Outside Temp
is Consistently
Use SAE
Viscosity Number
Below Zero. *5W-20
When Outside Temp
is Consistently
Use SAE
Viscosity Number
+70° F - 40° F. 5W-30
+70° F - -10° F. 10W-30
+120° F - + 10° F. 15W-40
