SECTION 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE
6-2 – JLG Lift – 3121321
6.2 OPERATING SPECIFICATIONS
Table 6-1. Operating Specifications
Maximum Working Height:
with outriggers deployed
with outriggers stowed
73.2 ft (22.3 m)
56.8 ft (17.3 m)
Maximum Platform Height :
with outriggers deployed
with outriggers stowed
66.7 ft (20.3 m)
50 ft (15.3 m)
Turning Radius (Outside)
14.8 ft
(4.5 m)
Maximum Work Load (Capacity) - Main Platform/
Platform Extension 1650 lbs/1100 lbs
(750 kg/500 kg)
Maximum Number of Persons 4
Tools and Equipment
Main Platform / Platform Extension 1300 lbs/397 lbs
(430 kg/180 kg)
Maximum Horizontal Manual Side Force
200 Lb force
(890N)
Tilt Sensor Setting 3°
Maximum Operating Wind Speed
28 mph
(12.5 m/s)
Gross Machine Weight (Approximate)
25,132 lbs
(11,400 kg)
Drive Speed (slow)
0.4 mph (0.6 ft/sec)
(0.2 m/s)
Drive Speed (fast)
2.2 mph (3.2 ft/sec)
(1 m/s))
Lift Speed (Platform Empty) 60 sec
Lowering Speed 60 sec
Sideslope (Machine Stowed) 5°
Gradeability (Machine Stowed) 25%
Maximum Operating Hydraulic Pressure
3046 psi
(210 bar)
Power Supply Diesel Engine
Maximum Ground Bearing Pressure:
Outrigger Pads
Tires
128 psi (9 kg/cm²)
71 psi (5 kg/cm²)
Maximum Tire Load
9700 lbs
(4400 kg)
Maximum Outrigger Pad Load
9548 lbs
(4290 kg)
Electrical System Voltage 24 V
Ground Clearance
0.9 ft
(0.27 m)
Table 6-1. Operating Specifications
