SECTION 1 - FRAME
38
M450A/M400AJPnarrow/M400A/E400AJPnarrow/E450A/E450AJ/E400A/M
3121830
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
46
Not Required
0
Standard Spec E/M450 Models (Prior to SN 0300059390)
46
1320172
1
Standard Spec E/M450 Models (SN 0300059390 through
0300189898)
46
1320172
1
Standard Spec E/M400 Models
50
0641524
4
Bolt 5/16in-18NC x 3in (E/M400) (SN 0300078578 through
0300189901)
50
0641524
4
Bolt 5/16in-18NC x 3in (E/M450) (SN 0300078578 through
0300189898)
51
2540020
1
Grommet (E/M400) (SN 0300101253 through 0300189901)
51
2540020
1
Grommet (E/M450) (SN 0300101253 through 0300189898)
52
2902046
Electrical Cable Kit (Includes Items 30 - 41)
1
1600294
Ref
CONTACTOR PLATE ASSEMBLY
E
98
7022003
1
Harness, Contactor (Not Shown) (See ELECTRICAL SECTION for
Breakdown)
99
7022004
1
Harness, Posi-Track Contactor (Not Shown) (See ELECTRICAL
SECTION for Breakdown)
100
7022005
1
Harness, Shunt (Not Shown) (See ELECTRICAL SECTION for
Breakdown)
101
7022002
1
Contactor (Forward/Reverse)
102
7022001
1
Contactor (Main)
103
7022000
1
Contactor (Posi-Track)
104
7022012
1
Cable, Power
105
7022011
1
Diode, Power
