SECTION 4 - PLATFORM
3121830
M450A/M400AJPnarrow/M400A/E400AJPnarrow/E450A/E450AJ/E400A/M
139
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
47
3571222
1
Angle, Relay Mounting Only (Prior to SN 0300068945)
48
4740120
4
Washer, Nylon Only (Prior to SN 0300068945)
49
3311005
4
Locknut #10-24NC Only (Prior to SN 0300068945)
51
Ref
Display - Light Panel Options:
51
1704239
1
Display (Prior to SN 0300139889)
51
1001110226
1
Display (E/M400) (SN 0300139889 through 0300189901)
51
1001110226
1
Display (E/M450A) (SN 0300139889 through 0300189898)
101
Ref
Decal Kit Options (Includes Items 15 - 20 & 51):
101
2910866
1
Kit (Prior to SN 0300139889)
101
1001119566
1
Kit (E/M400) (SN 0300139889 through 0300189901)
101
1001119566
1
Kit (E/M450) (SN 0300139889 through 0300189898)
0259102
Ref
JIB CONSOLE SWITCH (E/M450AJ & E/M400AJP ONLY)
2-B
201
4360328
1
Switch, Toggle
201
3790012
1
O-Ring
201
4922294
1
Harness, Jib Function (See ELECTRICAL SECTION for
Breakdown)
201
4240032
6
Tie-Strap
Ref
MOTOR CONTROLS INSTALLATION (M450 & M400 ONLY)
0257824
Ref
All M450 Models Built (Prior to SN 0300059390)
11
0270344
Ref
All M450 Models Built (SN 0300059390 through 0300079057)
5-B
0270344
Ref
All M400 Models (Prior to SN 0300079057)
5-B
0273573
Ref
All M450/M400 Models (SN 0300079057 through 0300088538)
B
0274617
Ref
Motor/Generator Installation (Kubota Diesel) (All M400 & M450
Models Built) (Prior to SN 0300182839)
G
1001159362
Ref
Motor/Generator Installation (Kubota Diesel) (All M400 Models
Built) (SN 0300182839 through 0300189901)
A
1001159362
Ref
Motor/Generator Installation (Kubota Diesel) (All M450 Models
Built) (SN 0300182839 through 0300189898)
A
301
4360336
1
Switch, Toggle
301
3790012
1
O-Ring
301
4922222
1
Harness (See ELECTRICAL SECTION for Breakdown)
301
4922223
1
Harness (See ELECTRICAL SECTION for Breakdown)
Ref
PLATFORM OVERLOAD SENSING INSTALLATION (OPTIONAL -
FRONT ENTRY PLATFORM)
0259358
Ref
CE Spec
D
0271489
Ref
CE Spec (Lift Down)
B
Ref
Note: For Side Entry Platform Refer to JLG Supplement
3124287.
401
1600310
1
Controller, Load Sensing
401
3910614
2
Screw #6-32NC x 7/8in
401
4750600
2
Flatwasher #6
401
3310601
2
Nut #6-32NC
0259338
Ref
WORKLIGHTS INSTALLATION (OPTIONAL)
C
501
Ref
Switch Options:
501A
4360336
1
Switch, Toggle (Prior to SN 0300161792)
501B
4360522
1
Switch, Push Button (E/M400) (SN 0300161792 through
0300189901)
501B
4360522
1
Switch, Push Button (E/M450) (SN 0300161792 through
0300189898)
502
1705170
1
Decal, Lights (E/M400) (SN 0300161792 through 0300189901)
502
1705170
1
Decal, Lights (E/M450) (SN 0300161792 through 0300189898)
