SECTION 3 - BOOM
102 M450A/M400AJPnarrow/M400A/E400AJPnarrow/E450A/E450AJ/E400A/M 3121830
ITEM PART NUMBER QTY DESCRIPTION REV
135 3311805 1 Locknut 1/2in-13NC
136 0641607 1 Bolt 3/8in-16NC x 7/8in
137 3422792 1 Pin
138 Ref Jib Assembly Options (Includes Items 1-27):
138 0259440 1 Jib Assembly E/M450AJ (Prior to SN 0300061430)
138 0270400 1 Jib Assembly E/M450AJ (SN 0300061430 through
0300189898)
139 0641809 1 Bolt 1/2in-13NC x 1-1/8in
144 0100011 AR Compound, Locking
Ref PLATFORM ROTATOR AND SUPPORT INSTALLATION (FRONT
ENTRY PLATFORM)
0259754 Ref E450AJ & M450AJ Models (Australian Spec) (Prior to SN
0300063775) 3/C
0270702 Ref E/M450AJ Models (CE Spec) (Prior to SN 0300063775) 2/B
0259439 Ref E/M450AJ Models (CE/Australian Specs) (SN 0300063775
through 0300189898) E
201 4846322 1 Weldment, Support
202 0681608 6 Bolt 3/8in-16NC x 1in (Grade 8)
203 0100011 AR Compound, Locking
204 0641407 2 Bolt 1/4in-20NC x 7/8in
205 4740362 4 Washer, Fender
206 3311405 2 Nut 1/4in-20NC
207 0641610 6 Bolt 3/8in-16NC x 1-1/4in
208 4711600 18 Flatwasher
209 3311605 6 Locknut 3/8in-16NC
Ref PLATFORM ROTATOR AND SUPPORT INSTALLATION (SIDE
ENTRY PLATFORM)
0272976 Ref E/M450AJ without Load Sensing A
See Note Ref E/M450AJ with Load Sensing (Note: Refer to JLG Supplement
p/n 3124287 for Components)
301 0100011 AR Compound, Locking
302 0641610 8 Bolt 3/8in-16NC x 1-1/4in
303 0681608 6 Bolt 3/8in-16NC x 1in (Grade 8)
304 3311605 8 Locknut 3/8in-16NC
305 4711600 16 Flatwasher 3/8in
306 Ref Weldment, Support Options:
306 4846608 1 Weldment, Support E/M450AJ without Load Sensing
306 See Note Above 1 Weldment, Support E/M450AJ with Load Sensing
307 4891600 6 Flatwasher 3/8in Hardened
