SECTION 4 - PLATFORM
124
M450A/M400AJPnarrow/M400A/E400AJPnarrow/E450A/E450AJ/E400A/M
3121830
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
111
3252347
1
Nameplate (Note: See DECAL SECTION for Other Languages)
112
4460071
1
Connector, Strain Relief
Ref
TRAY INSTALLATIONS (OPTIONAL)
201
1580012
1
Tray, Storage (Center)
202
1580013
1
Tray, Storage (Rail Mounted - Not Shown)
0259338
Ref
WORKLIGHTS INSTALLATION (OPTIONAL)
1-A
301
3536089
2
Plate, Mounting
302
0641414
4
Bolt 1/4in-20NC x 1-3/4in
303
3311405
4
Locknut 1/4in-20NC
304
4711400
8
Flatwasher 1/4in Narrow
305
2920095
2
Worklight
305
7016356
2
Bulb, Replacement (1 Per Assembly)
306
4240099
10
Tie-Strap (Not Shown)
307
2820035
9
Loom, Vinyl (Not Shown)
309
4460428
1
Connector, Strain Relief (Not Shown - Located at Console Box)
Ref
PLATFORM LOAD SENSING INSTALLATION (OPTIONAL)
0259358
Ref
CE Spec
D
0271489
Ref
CE Spec (Lift Down)
B
401
0100011
AR
Compound, Locking
402
0641404
2
Bolt 1/4in-20NC x 1/2in
403
0701010
2
Bolt, Metric 10mm x 20mm
405
1670905
1
Cover, Cell
408
3990108
1
Cell, Load
411
4711400
2
Flatwasher 1/4in Narrow
413
4812000
2
Lockwasher 7/16in
