SECTION 4 - PLATFORM
3121830 M450A/M400AJPnarrow/M400A/E400AJPnarrow/E450A/E450AJ/E400A/M 135
FIGURE 4-5. PLATFORM TOP RAIL EXTENSION INSTALLATION (SIDE ENTRY PLATFORM)
ITEM PART NUMBER QTY DESCRIPTION REV
Ref PLATFORM TOP RAIL EXTENSION INSTALLATION
1001103617 Ref 30in x 48in Platform A
1001103558 Ref 30in x 60in Platform A
1 0641416 8 Bolt 1/4in-20NC x 2in
2 3311405 8 Locknut 1/4in-20NC
3 3520182 6 Plug
4 4751400 16 Flatwasher 1/4in
5 4846759 1 Rail, Extension Gate
6 Ref Rail, Rear Extension Options:
6 1001103614 1 30in x 48in Platform
6 1001103559 1 30in x 60in Platform
7 Ref Rail, Extension Options:
7 1001103616 1 30in x 48in Platform
7 1001103560 1 30in x 60in Platform
