SECTION 8 DECALS
24
1702300
4
Decal - Tie Down /Lift
25
1701500
4
Decal - Tie Down /Lift
26
1701529
4
Decal - Arrow
27
AR
Decal Options:
3251242
1
240V-50Hz - Australian Spec
Not Required
0
All Other Specs
28
0860520
1
Box, Manual Storage
29
1060279
1
Cable, Lanyard
30
0641408
1
Bolt 1/4in-20NC x 1in
31
4751400
6
Flatwasher 1/4in Regular
32
3311405
5
Locknut 1/4in-20NC
33
Fastener Options:
2080057
2
Amtak
3820001
4
Rivet (Norwegian Spec Only)
34
1
Decal - Footswitch Options:
Not Required
Australian Spec
1703518
Dutch Spec
1693292
French Spec
1693294
German Spec
1701600
Italian Spec
1705275
Norwegian Spec
1701791
Spanish Spec
Not Required
UK Spec
35
Not Used
36
1701505
1
Decal - Fuel
37 to 42
Not Used
43
1704412
1
Decal - Hydraulic Fluid
44
3252768
1
Decal - Lift Diagram
45
1704885
2
Decal - Website
46
0641406
4
Bolt, 1/4in-20NC x 3/4in (Not Shown)
47
1705821
1
Decal, Tipping/Elect (PLF) (Not Shown)
48
1705822
1
Decal, Elect/Safety Manual (MTB) (Not Shown)
0010578
Ref
DECAL OPTIONS
120
0272165
Ref
Warning Stripe Decal Installation
4420051
21.7ft/6.61m
Decal - Warning Stripes
121 to 172
Not Used
173
Ref
Model Designation Decal Installation Options
0272580
Ref
450A Series II
2
173A
1704951
2
Decal - 450A
173B
1703486
4
Decal - Max Tire Load
0272581
Ref
450AJ Series II
2
173C
1704957
2
Decal - 450AJ
173D
1703486
4
Decal - Max Tire Load
FIGURE 8-6. DECALS INSTALLATION - AUSTRALIAN & CE SPECS (USA BUILT MACHINES
SN 0300069155 TO SN 0300074819 & BELGIUM BUILT MACHINES SN 1300000001 TO SN
1300000180) (CONTINUED)
ITEM #
PART NUMBER
QTY.
DESCRIPTION
REV.
