JLG 450A_AJ Series II Parts Manual User Manual
Page 136
2-58
SECTION 2 TURNTABLE
202
0080214
1
Adapter, Fan
203
0100011
AR
Compound, Locking
204
4711600
12
Flatwasher 3/8in Thin
205
0340041
2
Band, Muffler Bracket
206
0340046
2
Band, Muffler
207
0641406
7
Bolt 1/4in-20NC x 3/4in
208
0641414
4
Bolt 1/4in-20NC x 1-3/4in
209
0641506
2
Bolt 5/16in-18NC x 3/4in
210
0641507
4
Bolt 5/16in-18NC x 7/8in
211
0641609
4
Bolt 3/8in-16NC x 1-1/8in
212
0641610
18
Bolt 3/8in-16NC x 1-1/4in
213
0641612
8
Bolt 3/8in-16NC x 1-1/2in
214
0641820
4
Bolt 1/2in-13NC x 2-1/2in
215
Not Used
216
0700819
4
Bolt M8 x 55mm
217
0701012
4
Bolt M10 x 25mm
218
0701014
2
Bolt M10 x 30mm
219
0701022
2
Bolt M10 x 70mm
220
0641410
4
Bolt, 1/4in-20NC x 1-1/4in
221
0760606
4
Bolt M6 x 12mm
222
0902457
1
Bracket, Muffler
223
0962172
1
Bushing, Flanged
224
1320012
4
Clamp, Hose
225
1320016
4
Clamp
226
1320022
1
Clamp, Hose
227
1320033
8
Clamp, Hose
228
1320060
1
Clamp, Hose
229
1321138
3
Flange, Exhaust
230
1340060
1
Air Cleaner Assembly
7012664
1
Element, Air Cleaner
231 to 232
Not Used
233
2000207
1
Engine, Ford LRG-425 Tier II
234
2060025
1
Fan
235
2180467
1
Fitting, Barbed
236
2180798
1
Fitting, Restrictor Indicator (SN 0300078473 to SN
0300086917)
237
2720435
1
Hose, Radiator - Bottom
238
2720436
1
Hose, Radiator - Top
239
2720514
1
Hose, High Pressure Fuel Line
240
2820172
1
Shield, Insulated Exhaust
241
2820173
2
Shield, Insulated Exhaust
242
Not Used
243
3200406
4
Mount, Rubber
244
Not Used
245
0641604
1
Bolt 3/8in-16NC x 1/2in
246
3311405
13
Locknut 1/4in-20NC
247
3311505
6
Locknut 5/16in-18NC
248
3311605
24
Locknut 3/8in-16NC
249
3311805
4
Locknut 1/2in-13NC
FIGURE 2-11. USA BUILT MACHINES/FORD ENGINE INSTALLATION (SN 0300078473 TO SN
0300124000) (CONTINUED)
ITEM #
PART NUMBER
QTY.
DESCRIPTION
REV.
