3-10
SECTION 3 BOOM
103
0561076
1
Block, Boom Rest
104
0641610
6
Bolt 3/8in-16NC x 1-1/4in
105
0642012
4
Bolt 5/8in-11NC x 1-1/2in
106
0642014
2
Bolt 5/8in-11NC x 1- 3/4in
107
0642016
2
Bolt 5/8in-11NC x 2in
108
0801356
1
Boom, Mid
109
0801357
1
Boom, Tower
110
0961950
20
Bearing, Garmax
111
Not Used
112
3311605
6
Locknut 3/8in-16NC
113
3312005
2
Locknut 5/8in-11NC
114
3422568
6
Pin
115
3422912
2
Pin
116
3841258
8
Keeper, Pin
117
4751600
14
Flatwasher 3/8in Regular
118
1
Rest, Boom Options:
Use 4846905
Prior to SN 1300000414 (was p/n 4846428)
4846905
SN 1300000414 to SN 1300006000
119
4846697
1
Upright (Upper)
120
2
Link Options:
Use 3010140
Prior to SN 1300000905 (was p/n 4846700)
3010140
SN 1300000905 to SN 1300006000
121
4846701
1
Link, Timing
122
4846703
1
Upright (Lower)
123
3340608
1
Pad, Wear
124
0641605
2
Bolt, 3/8in-16NC x 3/8in
125
3574066
1
Cover (1300001679 to SN 1300006000)
Ref
BOOM CABLES AND CLAMPS INSTALLATIONS
0272594
Ref
450AJ Series II
D
0275436
Ref
450AJ Series II with SkyPower
D
Ref
Note: For Additional Components See ELECTRICAL
SECTION
201
0561460
1
Block, Clamp
202
0630498
1
Bolt
203
0641528
3
Bolt 5/16in-18NC x 3-1/2in
204
AR
Cable, Electrical Options (Not Shown - See ELECTRICAL
SECTION):
1060991
1
Without SkyPower (12/3 AC Power Cable)
Use 4922857
1
With SkyPower (Prior to SN 130002739) (was p/n 4922929)
4922857
1
With SkyPower (SN 1300002739 to SN 1300006000)
205
1320300
1
Clamp, Hose
206
3300420
1
Nut, Acorn 1/4in-20NC
207
3311605
3
Locknut 3/8in-16NC
208
3860096
1
Roller
209
4061032
2
Shield, Cable
210
4240018
7
Tie-Strap (Not Shown)
FIGURE 3-2. TOWER/MID BOOMS AND CYLINDERS INSTALLATION (BELGIUM BUILT
MACHINES) (CONTINUED)
ITEM #
PART NUMBER
QTY.
DESCRIPTION
REV.
