SECTION 3 BOOM
54
3572826
1
Cover
55 to 56
Not Used
57
3841258
12
Keeper, Pin
58
Not Used
59
4751500
4
Flatwasher 5/16in Regular
60
4751600
AR
Flatwasher 3/8in Regular
61 to 62
Not Used
63
1
Upright (Upper) Options:
4846366
450A Series II
4846335
450AJ Series II
64
4846336
2
Link
65
4846343
1
Link, Timing
66
4846346
1
Upright (Lower)
67
Not Used
68
1
Rest, Boom Options:
68A
3572750
450A Series II
68B
4846428
450AJ Series II
69
0641507
2
Bolt 5/16in-18NC x 7/8in
70
1671013
1
Cover
71
3340914
1
Pad
72
4711500
2
Flatwasher 5/16in Thin
73
1
Cable, Electrical 18/2 Options (Not Shown):
4922770
Without Arctic Package
4923469
With Arctic Package
Ref
BOOM CABLES AND CLAMPS INSTALLATIONS
0271311
Ref
450A Series II (ANSI/ANSI Export /CSA Specs)
J
0271310
Ref
450A Series II (Australian/CE Specs)
J
0273279
Ref
450A Series II (All Specs with SkyPower)
C
1001097502
Ref
450A Series II (All Specs with Arctic Package)
A
1001097503
Ref
450A Series II (All Specs with Arctic Package & SkyPower)
A
0271122
Ref
450AJ Series II (ANSI/ANSI Export /CSA Specs)
J
0271206
Ref
450AJ Series II (Australian/CE Specs)
J
0273280
Ref
450AJ Series II (All Specs with SkyPower)
C
0275116
Ref
450AJ Series II (All Specs with Arctic Package)
C
0275786
Ref
450AJ Series II (All Specs with Arctic Package & SkyPower)
C
Ref
Note: For Additional Components See ELECTRICAL
SECTION
101 to 104
Not Used
105
4460425
1
Connector, Strain Relief
106 to110
Not Used
111
4751400
2
Flatwasher 1/4in Regular
112
Not Used
113
1
Harness, Tower Boom Options (Not Shown - See ELECTRICAL
SECTION):
4922530
Without Arctic Package
4923458
With Arctic Package
114
Not Used
FIGURE 3-1. TOWER/MID BOOMS AND CYLINDERS INSTALLATION (USA BUILT MACHINES)
(CONTINUED)
ITEM #
PART NUMBER
QTY.
DESCRIPTION
REV.
