2-104
SECTION 2 TURNTABLE
9B
1
Control Box Options:
110V/60Hz
7003657
Prior to SN 0300087209
7019680
SN 0300087209 to SN 0300124000
220V/50Hz
70002235
Prior to SN 0300087209
70000127
SN 0300087209 to SN 0300124000
1
Circuit Breaker Options:
4360542
110V/60Hz
70000126
220V/50Hz
4460190
AR
Receptacle, Double (110V Box)
4460027
AR
Receptacle, Double Twist Lock (110V Box)
70000124
1
Receptacle, Double (220V Box)
70000125
1
Receptacle, Single Twist Lock (220V Box)
2920162
1
Lamp Assembly (Prior to SN 0300087209)
7020191
1
Switch, Toggle (Prior to SN 0300087209)
3520028
1
Plug, Power
9C
1
Voltmeter Options:
2420203
1
110V
7020192
220V
9D
1
Pulley Options:
3580276
110V
3580134
220V
7027887
1
Key, Woodruff
10
2820031
1
Heatshrink (Not Shown - Located at Platform)
11
3251102
1
Decal (Located at Platform)
12
3311005
2
Locknut #10-24NC
13
3311605
1
Locknut 3/8in-16NC
14
3311705
1
Locknut 7/16in-14NC
15
3520028
1
Plug, Hole
16
3580315
1
Pulley
17
3740080
1
Relay (Not Shown - Located Back SIde of Engine Tray with
Existing Relays)
18
4060802
1
Guard, Switch (Located at Platform)
19
4360336
1
Switch, Toggle (Located at Platform)
20
4460023
1
Connector, Strain Relief
21
4751000
8
Flatwasher #10 Regular
22
4751500
1
Flatwasher 5/16in Regular
23
4751600
6
Flatwasher 3/8in Regular
FIGURE 2-18. 2500W GENERATOR INSTALLATION - CATERPILLAR ENGINES (USA BUILT
MACHINES) (OPTIONAL) (CONTINUED)
ITEM #
PART NUMBER
QTY.
DESCRIPTION
REV.
