2.1.4 TECHNICAL SPECIFICATIONS
NB: Side extension is measured from the centre of the turntable to the outside edge of the
basket.
BOOM LIFT MODELS X20JPLUS
JLG
14 X20JPR0020413
PLATFORM CAPACITY 230 kg
PLATFORM HEIGHT (floor) 18,05 m
MAX WORKING HEIGHT 20,15 m
STANDARD BASKET DIMENSIONS 1335 x 690 x H1100 mm
MAX HORIZONTAL EXTENSION IN BASKET 9,20 m
MAX HORIZONTAL OUTREACH 9,70 m
ROTATION (non-continuous) 360°
BASKET ROTATION 124° (+/- 62°)
MAX GROUND REACTION FORCE FOR EACH
STABILISER
2150 daN
MAX GROUND PRESSURE FOR EACH STABILISER 3,04 daN/cm 2
NO. OF OPERATORS 2
NO. OF OPERATORS WITH OPTIONAL SINGLE-OPERATOR
BASKET
1
JIB - TYPE OF ARTICULATED JOINT 89°(+0°/-89°)
MAX WORKING GRADIENT 1°/1,75%
MAX STABILISATION SLOPE 15°
TOTAL WEIGHT IN TRANSPORT CONFIGURATION
(PETROL ENGINE)
2880 kg
ENGINE
HONDA iGX440 - (12,7 cv) / 3600 rpm
PERKINS 402.05 - (14 cv) / 3600 rpm
ELECTRIC MOTOR 2,2 kw / 230V / 50Hz 1500 rpm
ELECTRICAL SYSTEM VOLTAGE 12 V
PUMPS PETROL ENGINE double 2x4 cm³
PUMPS DIESEL ENGINE double 2x4 cm³
MAX TRANSLATION SPEED WITH STANDARD 2 ND SPEED
(thermic motor)
0,5/1,3 / 2,5 Km/h
TRAVEL/STAB. SYSTEM PRESSURE 165 bar
AERIAL PART SYSTEM PRESSURE 210 bar
MAX SLOPE ALLOWED IN TRAVEL DIRECTION 15°
MAX WIND SPEED 12,5 m/s
MAX MANUAL FORCE ALLOWED 400 N
