RECOMMENDED SPARE PARTS
The following list will service fleets of machines (built to current production per date on the front cover) with repair
parts which can be installed in the field. Parts from the list should be replaced when inventory is depleted to keep
service parts stock supplied. For further information, contact your JLG dealer or the JLG Industries Parts Department.
3121859 4017 13-1
SECTION 13
RECOMMENDED SPARE PARTS
Part Number Description Qty./Machine
BOOM ASSEMBLY
2754157 Tilt Cylinder Hoses, (see Figure 8-6) 1
2754158 Tilt Cylinder Hoses, (see Figure 8-6) 1
2754141 Boom Hoses, (right), (see Figure 8-8) 1
2754150 Boom Hoses, (left), (see Figure 8-8) 1
2754236 Boom Hoses, (right), (see Figure 8-6) 1
2754140 Boom Hoses, (left), (see Figure 8-7) 1
3580336 Hose Sheave, (see Figure 2-3) 2
4700021 Bearing Pad, (see Section 2) 8
4700030 Bearing Pad, (see Section 2) 1
4700031 Bearing Pad, (see Section 2) 1
4700032 Bearing Pad, (see Section 2) 6
1001093784 Bearing Pad, (see Section 2) 4
8002200 Bearing Pad, (see Section 2) 24
8002201 Bearing Pad, (see Section 2) 4
8010148 Bearing Pad, (see Section 2) 2
4071085 Shims, 2.0MM, (see Section 2) AR
4071087 Shims, 4.0MM, (see Section 2) AR
4071093 Shims, 2.0MM, (see Section 2) AR
4071098 Shims, 3.0MM, (see Section 2) AR
4071099 Shims, 2.0MM, (see Section 2) AR
8002904 Shims, 1.0MM, (see Section 2) AR
8003242 Shims, 1.0MM, (see Section 2) AR
8008070 Shims, 2.0MM, (see Section 2) AR
8009987 Shims, 2.0MM, (see Section 2) AR
3964987 Quick Release Pin, (see Figure 2-9) 1
ENGINE
8006013 Oil Filter, (see Figure 4-2) 1
7028655 Fuel Filter, (see Figure 4-2) 1
80273010 Air Filter Element, (see Figure 4-5) 1
80273042 Air Filter Safety Element, (see Figure 4-5) 1
3929100 Air Circulation Filter Element, (see Figure 6-8) 1
8003285 Fuel Tank Cap, (Before S/N 1160000822), (see Figure 4-3) 1
7029215 Fuel Tank Cap, (S/N 1160000822 & After), (see Figure 4-3) 1
2060033 Fan, (see Figure 4-1) 1
7028686 Alternator Belt, (see Figure 4-2) 1
7028672 Dipstick, (see Figure 4-2) 1
DRIVE TRAIN
91473031 FNR Shifter, (see Figure 7-1) 1
8002599 Accelerator Cable, (see Figure 4-1) 1
8008101 Transmission Filter, (see Figure 4-13) 1
7028718 Wheel End Seal, (see Section 5) 2
8004468 Wheel End Bushing, (see Section 5) 2
91514111 Wheel End Bushing, (see Section 5) 2
7029430 Wheel Hub Seal, (see Section 5) 2
