ELECTRICAL
4017 3121859 10-8
Figure 10-4 Electrical Installation, Cab
(S12)
(S30)
(X20)
45
49
(X16.1)
58
57
56
55
ESX
(X22)
(X10)
(X16)
0 4/4
40 120
80 100
C
31
30
P01
P02
51
(X11)
52
(X01)
(M02)
34
49
(X27)
28
(M03)
38
(A7.1)
(A7.2)
22
43
(S01)
11
(S02)
10
(X06)
39
5
24
6
25
25 (A01)
(S07)
PULL RELIEF
66
68 65
67
71
72
35
(S14)
53
9
8
(S03)
13
(H04)
14
(H01)
15
(H02)
12
21
18
(S11) 7
19
20
76
114
115
5
(X17)
(X19)
(X18)
34
35
(M08)
(X189)
(X07)
3
(X08)
(X05)
(X04)
48
47
46
(X03)
(X02)
3
2
47
47
48
46
(X23)
(X06)
(X15)
40
63
36
40
23
1
(S04)
44
29
(X24)
73
75 64
A01------------- ESX
A03------------- DISPLAY
A7.1, 7.2------ LMI
H01------------- HIGH BEAM PILOT LIGHT
H02------------- DIRECTION INDICATOR PILOT LIGHT
H03------------- INDICATOR PILOT LIGHT TRAILER, (In HYDRAULIC HITCH KIT)
H04------------- CHARGING WARNING LIGHT)
M02-------------HEATER FAN, (in UNIT FOR HEAT ONLY; in AIR CONDITIONING UNIT INSTALLATION)
M03-------------WIPER FRONT
M08-------------AIR SUSPENSION SEAT OPTION
P01------------- TEMPERATURE DISPLAY ENGINE
P02------------- FUEL GAUGE
S01------------- SWITCH IGNITION
S02------------- WARNING FLASHER SWITCH
S03------------- DRIVING LIGHTS SWITCH
S04------------- SIGNAL and WIPER CONTROL
S07------------- SWITCH PARKING BRAKE
S09------------- SWITCH WORK LIGHTS FRONT, (in WORK LIGHT FRONT KIT)
S10------------- SWITCH WORK LIGHTS REAR, (in WORK LIGHTS REAR KIT)
S11------------- SWITCH WIPER REAR
S12------------- SWITCH HEATER FAN, (in UNIT FOR HEAT ONLY; in AIR CONDITIONING UNIT INSTALLATION)
S14------------- SWITCH WARNING BEACON
S15------------- SWITCH 2.AUXILIARY HYDRAULIC, (in 2. AUXILIARY HYDRAULIC KIT)}
S17------------- SWITCH AUXILIARY HYDRAULIC CONTINUOUS OPERATION, (in 1. AUXILIARY HYDRAULIC KIT)
S18------------- SWITCH LEVELING
S27------------- SWITCH WORK FLASHER BOOM (in WORKLIGHT BOOM KIT)
S30------------- SWITCH AIR CONDITIONING (in AIR CONDITIONING KIT)
X01------------- POWER SUPPLY
X02-04--------- CABLE INSTRUMENT PANEL
X05-08--------- CABLE STEAR COLUMN CABIN BOTTOM
X10,16, 16.1,22--CABLE FRONT END GEAR UNIT
X11------------- CABLE ENGINE
X12, 13-------- CABLE REAR
X15------------- JOYSTICK
X16.1, 17-19- CABLE ESX
X20------------- 12V POWER OUTLET IN CABIN
X23, 24-------- CABLE FNR GEAR SHIFT CONTROL
X27------------- LEFT DRIVING LIGHT
X189----------- AIR CONDITIONING OPTION
XJXPE-------- JOYSTICK CASE GROUND
62
X12/X13
X11
X01
61
X10/X16/X22
61
(X12)
48
50
47
(X13)
(X07)
(A03)
74
(XJXPE)
(X99)
3
3
SEE GEAR & VALVE
(X15A)
(X15)
(X15B)
78
X15A----------- SDIO CAN BUS
X15B----------- TEE’D INTO JOYSTICK CONNECTION
X99------------- SDIO MODULE
79
(X99)
101
103
102
104
PAP071
95
96
