JLG M400 Operator Manual - Manual (Page 97)

SECTION 6 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE
3121215 – JLG Lift – 6-5
Dimensional Data
Torque Specifications
Table 6-5. Dimensional Data
Machine Length (stowed)
E/M400A; E/M400An
E/M400AJP; E/M400AJPn
18 ft. 1 in. (5.50 m)
22.0 ft. (6.7 m)
Machine Height (stowed)
E/M400A; E/M400AJP
E/M400An; E/M400AJPn
6 ft. 7 in. (2.0 m)
6 ft. 5.75 in. (1.31m)
Up and Over Platform Height 21 ft. 5 in. (6.55 m)
Horizontal Reach @ Maximum
Up and Over
E/M 400A, E/M 400An
E/M400AJP, E/M400AJPn
21 ft. 2 in. (6.41 m)
22 ft.-5 in. (6.83 m)
Machine Width
E/M400A; E/M400AJP
E/M400An; E/M400AJPn
5 ft. 9 in. (1.75 m)
4 ft. 11 in. (1.50 m)
Wheel Base 6 ft. 7.0 in. (2.00 m)
Working Height 46 ft. 0 in. (14.02 m)
Platform Height 40 ft. 0 in. (12.19 m)
Track Width
E/M400A; E/M400AJP
E/M400An; E/M400AJPn
5 ft. 0 in. (1.51 m)
4 ft. 3.75 in.(1.31 m)
Tail Swing (Any Position)
E/M 400A, E/M400AJP, E/
M400AJPnarrow
E/M 400Anarrow
0
4 in. (10 cm)
Ground Clearance
E/M 400A, E/M400AJP
E/M 400An, E/M400AJPn
8.5 in. (0.22 m)
5 in. (0.13 m)
Table 6-6. Torque Requirements
Description Torque Value Interval Hours
Wheel Lugs 170 ft. lbs. (230 Nm) 150
Swing Bearing (Loctite) 190 ft. lbs.(260Nm) 50/600*
* Check swing bearing bolts for security after first 50 hours of
operation and every 600 hours thereafter.
Table 6-5. Dimensional Data
