SECTION 6 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE
6-2 – JLG Lift – 3121215
Maximum Tire Load:
E/M 400A
E/M 400Anarrow
E/M400AJP
E/M400AJPnarrow
5370 lbs. (2436 kg)
4700 lbs. (2132 kg)
6260 lbs. (2840 kg)
7160 lbs. (3248 kg)
Ground Bearing Pressure
E/M 400A
E/M 400Anarrow
E/M400AJP
E/M400AJPnarrow
57 psi (4.0kg/cm 2 )
104 psi (7.3 kg/cm 2 )
74 psi (5.2 kg/cm 2 )
185 psi (13.0 kg/cm 2 )
Drive Speed: (Above Horz.)
E/M400A; E/M400AJP
E/M400An; E/M400AJPn
42-44 sec / 200 ft.
50-53 sec / 50 ft.
45-50 sec / 200 ft.
55-68 sec / 50 ft.
Gross Machine Weight
E/M400A
E400An
M400An
E400AJP
M400AJP
E400AJPn
M400AJPn
12100 lb. (5,488 kg)
13100 lb. (5942 kg.)
13300 lb. (6033 kg.)
13700 lb. (6214 kg.)
13930 lb. (6319 kg)
14900 lb. (6759 kg.)
15130 lb. (6863 kg.)
Table 6-1. Operating Specifications - Prior to S/N 0300142589
Maximum System Voltage 48 VDC
Battery Life per Charge 7 hours continuous
Battery Recharge Time
Charger
Generator
17 hours from full discharge
6.2 hours
Maximum Main Relief Hyd. Pressure 3400 psi
(234 bar)
Table 6-2. Operating Specifications - S/N 0300142589 to
Present
Maximum Work Load (Capacity)
ANSI Markets
Unrestricted:
500 lb. (227 kg)
Maximum Work Load (Capacity)
CE & Australia Markets
Unrestricted:
500 lb. (230 kg)
Maximum Travel Grade, Stowed Position
(Gradeability) 2 W/D-30%
Maximum Travel Grade, Stowed Position
(Side Slope) 5 degrees
Platform Height: 40 ft. (12.19 m)
Table 6-1. Operating Specifications - Prior to S/N 0300142589
