SECTION 6 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE
3121215 – JLG Lift – 6-1
SECTION 6. GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE
6.1 INTRODUCTION
This section of the manual provides additional necessary
information to the operator for proper operation and mainte-
nance of this machine.
The maintenance portion of this section is intended as infor-
mation to assist the machine operator to perform daily main-
tenance tasks only, and does not replace the more thorough
Preventive Maintenance and Inspection Schedule included
in the Service and Maintenance Manual.
Other Publications Available:
Service and Maintenance Manual - ANSI, CSA Spec3121125
Service and Maintenance Manual - CE Spec........... 3121827
Illustrated Parts Manual - ANSI, CSA Spec .............. 3121128
Illustrated Parts Manual - CE Spec........................... 3121830
6.2 OPERATING SPECIFICATIONS
Table 6-1. Operating Specifications - Prior to S/N 0300142589
Capacity: Unrestricted: 500 lbs.
(230 kg.)
Maximum Travel Grade, Stowed Position
(Gradeability) 2 W/D-30%
Maximum Travel Grade, Stowed Position
(Side Slope) 5 degrees
Platform Height: 40 ft. (12.19 m)
Horizontal Platform Reach (Up & Over)
E/M400A; E/M400An
E/M400AJP; E/M400AJPn
21 ft.-2 in. (6.41 m.)
22 ft.-5 in.(6.8 m.)
Machine Width:
E/M400A; E/M400AJP
E/M400An; E/M400AJPn
5 ft.-9 in. (1.75 m.)
4 ft.-11 in. (1.50 m.)
Turning Radius (Outside) 10 ft.-4 in. (3.15 m.)
Turning Radius (Inside)
E/M400A; E/M400AJP
E/M400An; E/M400AJPn
2 ft.-0 in. (0.61 m.)
2 ft.- 10 in. (0.86 m.)
