Section 5 - Attachments and Hitches
5-6 31200205
Sample Capacity Chart (CE)
Note: This is a sample capacity chart only! DO NOT use this chart, use the one
located in your operator cab.
WARNING
TIP OVER HAZARD. All loads shown on rated capacity chart are based on
machine being on firm ground with frame level (see page 4-5); the forks being
positioned evenly on carriage; the load being centered on forks; proper size tires
being properly inflated; and the telehandler being in good operating condition.
XXXXXXX
EN 1459 B (1998)
XXXX
P/N 1122334
P/N 9988776
P/N 1234567
P/N 9876543
4.000kg
3.500kg
3.000kg
2.500kg
2.000kg
1.500kg
1.000kg
500kg
750kg
400kg
0
m
9
0°
10°
20°
30°
40°
50°
60°
70°
A
B
C
D
E
F
G
1
2
3
4
5
6
7
8
9
10
11
12
13
14
8 7 6 5 4 3 2 1 0
2000kg
OZ0640
Boom Extension
Indicator (arc)
Load zones indicate
the maximum weight
that may be safely lifted.
These numbers must match the
model/option number stamped
on the attachment ID Plate.
Boom Angle
This Capacity Chart may be used with this model ONLY.
The telehandler model is indicated on the boom or chassis.
Model XXXX is used for demonstration purposes only.
