Section 3 - Controls and Indicators
3-3
31200205
9. Frame Level Indicator: Enables operator to determine the left to right level
condition of the telehandler.
10. Steering Column Adjuster: See page 3-17.
11. Steering Wheel: Turning the steering wheel to the left or right steers the
machine in the corresponding direction. Three steering modes are available.
See “Steer Modes” on page 3-26.
12. Instrument Panel: See page 3-4.
13. Accessory Control Lever: See page 3-24.
14. LSI Indicator: See page 3-14.
15. Keypad: See page 3-8.
16. Joystick: See page 3-18.
17. Longitudinal Level Indicator (AUS): Enables the operator to determine the front
to back level condition of the telehandler.
18. Armrest and Right Hand Console: See page 3-22.
19. Hydraulic Hitch Safety Hook Release (8 & 9M, if equipped): Pull to release
safety hooks on hydraulic hitch. See page 5-46 for control instructions.
