JLG 1250AJP Parts Manual User Manual
Page 325
SECTION 7 - ELECTRICAL
3121172
1250AJP
325
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
807J
4460476
1
Receptacle, Female - 3 Position (4922991 Harness)
807J
4460850
3
Pin, Male (4922991 Harness)
807J
4460458
3
Seal, Terminal (4922991 Harness)
807J
1001098349
1
Connector, Male (1001098448 Harness)
808
Ref
Work Lights Harness Components
808A
2400066
1
Fuseholder
808A
2400070
AR
Fuse 20 Amp
808B
See Note
2
Work Light Harness (Supplied with Work Light) (Note: Not
Available for Purchase)
808C
4460426
1
Connector, Strain Relief
808D
4922990
1
Light Harness (Main Boom) (Use p/n 1001098451)
A
808E
4460459
1
Plug, Male - 3 Position (4922990 Harness)
808E
4460790
3
Socket, Female (4922990 Harness)
808E
4460458
3
Seal, Terminal (4922990 Harness)
808E
1001098234
1
Connector, Female (1001098449 Harness)
808F
4922991
1
Light Harness (Tower Boom) (Use p/n 1001098450)
A
808G
4460476
1
Receptacle, Female - 3 Position (4922991 Harness)
808G
4460850
3
Pin, Male (4922991 Harness)
808G
4460458
3
Seal, Terminal (4922991 Harness)
808G
1001098349
1
Connector, Male (1001098448 Harness)
Ref
TOOLS (NOT SHOWN)
7002821
1
Crimper (For Wire to Pin/Socket Connections)
7002823
1
Extractor (For Removal of Pin/Socket from Connectors)
4460467
1
Extractor, Pin (Blue 16-18 Gauge) (For Removal of Pin/Socket
from Connectors)
4460510
1
Extractor, Pin (Yellow 12-14 Gauge) (For Removal of Pin/Socket
from Connectors)
7002828
1
Stripper, Wire
