SECTION 2 - TURNTABLE
116 1250AJP 3121172
ITEM PART NUMBER QTY DESCRIPTION REV
304L 7024906 1 Pin, Cylinder
305 70003165 1 Control Module
305A See Note 1 Valve Body, Lever and Internal Components (Note: Not
Available - Purchase Complete Module)
305B 70003170 2 Coil, Solenoid
305C 70003165 2 Spacer, Coil
305D 70020336 1 Gasket
305E 70003165 1 Cover W/Filter
305F 70003165 1 Spring, Draw
305G 70020336 1 Gasket
305H See Note 4 Capscrew M6 x 65mm (Note: Not Available - Purchase Locally)
305J See Note 1 Capscrew M6 x 45mm (Note: Not Available - Purchase Locally)
305K See Note 8 Capscrew M5 x 10mm (Note: Not Available - Purchase Locally)
305L 70020336 1 O-Ring
305M 70003165 2 O-Ring
305N 70003165 2 Cup, Spring
305P 70020336 2 Pin, Cylinder
305Q 70003165 2 Nut, Coil
310 See Note 1 Housing (Note: Not Available for Purchase)
313 See Note 2 Pin, Dowel (Note: Not Available for Purchase)
314 See Note 1 Pin, Cylinder (Note: Not Available for Purchase)
320 See Note 1 Screw 7/8-14NF (Front Drive Pump Only) (Note: Not Available -
Purchase Locally)
321 See Note 1 Screw 9/16-18NF (Note: Not Available - Purchase Locally)
322 See Note 1 Screw 7/16-20NF (Note: Not Available - Purchase Locally)
324 See Note 1 Screw M10 x 1mm (Note: Not Available - Purchase Locally)
327 70003166 1 Pin, Double Break-Off
328 70003166 2 Orifice
331 70003166 2 Pin, Clamping
341 70003166 1 O-Ring
Ref Seal Kit Options:
401 70003167 1 Seal Kit - Drive Shaft (Includes Items 301L & 301M)
402 70003168 1 Seal Kit - Control Group - Hydraulic (Includes Items 302B, 302D
& 302E)
403 70003169 1 Seal Kit - Port Plate Group (Includes Items 303F-303K)
404 70020336 1 Seal Kit - Control Module (Includes Items 305D, 305G-305J,
305L & 305P)
405 70003166 1 Seal Kit - Front Pump (Includes Items 320-322, 324, 327, 328,
331 & 341)
