SECTION 6 - HYDRAULIC
304 1250AJP 3121172
FIGURE 6-7. HYDRAULIC DIAGRAM LIST
ITEM PART NUMBER QTY DESCRIPTION REV
Ref HYDRAULIC DIAGRAM - BOOM
1283457 Ref Hydraulic Diagram for Caterpillar Engine Machines with
Rexroth Pumps
1283374 Ref Hydraulic Diagram for Caterpillar Engine Machines with
Rexroth Pumps
1283457 Ref Hydraulic Diagram for Deutz BF4M2011 AND TD2011 Engine
Machines with Rexroth Pumps
1283374 Ref Hydraulic Diagram for Deutz BF4M2011 & TD2011 Engine
Machines with Rexroth Pumps
1001152971 Ref Hydraulic Diagram for Deutz TCD2.9L4 Engine Machines with
Rexroth Pumps
2792628 Ref Prior to SN 0300119708 (with 2-Port Design Rotators)
1001098027 Ref SN 0300119708 to Present (with 3-Port Design Rotators)
1001110252 Ref Hydraulic Diagram for Machines with Sauer Pumps
1001111084 Ref All Machines
Ref HYDRAULIC DIAGRAM - DRIVE
1283457 1 Hydraulic Diagram for Caterpillar Engine Machines with
Rexroth Pumps
1283374 1 ref Hydraulic Diagram for Caterpillar Engine Machines with
Rexroth Pumps
1283457 Ref Hydraulic Diagram for Deutz BF4M2011 & TD2011 Engine
Machines with Rexroth Pumps
1283374 Ref Hydraulic Diagram for Deutz BF4M2011 & TD2011 Engine
Machines with Rexroth Pumps
1001152971 Ref Hydraulic Diagram for Deutz TCD2.9L4 Engine Machines with
Rexroth Pumps
2792645 Ref Hydraulic Diagram (Prior to SN 0300103907)
2792772 Ref Hydraulic Diagram (SN 0300103907 to Present)
1001110252 Ref Hydraulic Diagram for Machines with Sauer Pumps
1001111082 Ref All Machines
Ref HYDRAULIC DIAGRAM - OSCILLATING AXLE
1283457 Ref Hydraulic Diagram for Caterpillar Engine Machines with
Rexroth Pumps
1283374 Ref Hydraulic Diagram for Caterpillar Engine Machines with
Rexroth Pumps
1283457 Ref Hydraulic Diagram for Deutz BF4M2011 & TD2011 Engine
Machines with Rexroth Pumps
1283374 Ref Hydraulic Diagram for Deutz BF4M2011 & TD2011 Engine
Machines with Rexroth Pumps
1001152971 Ref Hydraulic Diagram for Deutz TCD2.9L4 Engine Machines with
Rexroth Pumps
2792647 Ref All Machines
1001110252 Ref Hydraulic Diagram for Machines with Sauer Pumps
1001111081 Ref All Machines
Ref HYDRAULIC DIAGRAM - STEER
1283457 Ref Hydraulic Diagram for Caterpillar Engine Machines with
Rexroth Pumps
1283374 Ref Hydraulic Diagram for Caterpillar Engine Machines with
Rexroth Pumps
1283457 Ref Hydraulic Diagram for Deutz BF4M2011 & TD2011 Engine
Machines with Rexroth Pumps
1283374 Ref Hydraulic Diagram for Deutz BF4M2011 & TD2011 Engine
