SECTION 1 - FRAME
12
1250AJP
3121172
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
0300080868)
46
4360578
4
Switch, Limit (SN 0300080869 to Present)
47
4711600
140
Flatwasher 3/8in Thin
48
4740461
1
Thrustwasher
49
4750800
8
Flatwasher #8 Regular
50
4846637
4
Extension, Axle
51
4846383
1
Box, Axle Pivot
52
0681813
12
Bolt 1/2in-13NC x 1-5/8in (Grade 8)
53
0681814
18
Bolt 1/2in-13NC x 1-3/4in (Grade 8)
54
0681815
12
Bolt 1/2in-13NC x 1-7/8in (Grade 8)
55
0681816
6
Bolt 1/2in-13NC x 2in (Grade 8)
56
4711800
48
Flatwasher 1/2in Thin
57
4460968
4
Connector, Strain Relief
Ref
AXLE INSTALLATION - OPTIONAL PARTS
0271934
Ref
Fixed Axle
K
105
0363076
2
Bar, Stop
115
0641814
4
Bolt 1/2in-13NC x 1-3/4in
144
4071049
6
Shim 11 Gauge
145
4071050
4
Shim 16 Gauge
0271521
Ref
Oscillating Axle
K
201 to 211
Ref
(Illustration and Parts List Usage)
212
0642020
4
Bolt 5/8in-11NC x 2-1/2in
217
1684081
2
Oscillating Axle Cylinder Assembly (See CYLINDER SECTION
for Breakdown)
220
3312005
4
Locknut 5/8in-11NC
225
3422833
2
Pin
226
3422915
2
Pin
231
3841258
4
Keeper, Pin
246
4712000
4
Flatwasher 5/8in Thin
254
3520054
4
Plug
0274106
Ref
AXLE STOP BLOCKS INSTALLATION
A
301
0100019
AR
Compound, Locking
302
3931816
4
Capscrew, Socket Head 1/2in-13NC x 1in
303
4220235
2
Block, Stop
