7-46
SECTION 7 ELECTRICAL
FIGURE 7-10. HARNESS COMPONENTS INSTALLATION (DEUTZ EMR2) (S/N 85132 TO
ITEM #
PART NUMBER
QTY.
DESCRIPTION
REV.
4922639
Ref.
PLATFORM BOX HARNESS ASSEMBLY
7/H
1 to 18
Not Used
19
4460866
1
Terminal, 19 Pin Receptacle
20
4460874
1
Connector - 35 Position (Natural)
21
4460875
1
Connector - 35 Position (Gray)
22
4460873
1
Connector - 35 Position (Black)
23
4460871
A/R
Socket, Female
24
4460464
7
Pin, Male (16 Gauge)
25
4460879
1
Terminal, Housing 2 Position
26
4460887
2
Terminal, (12 Gauge)
27 to 29
Not Used
30
4460418
9
Connector - 6 Position
31
4460419
27
Terminal, Female
32
4120035
A/R
Base, Light
33 to 35
Not Used
36
4460225
1
Plug, Male- 6 Position
37
4460227
6
Pin, Male
38 to 40
Not Used
41
4460508
3
Pin, Male (12 Gauge)
42
Not Used
43
4460434
2
Connector - 15 Position
44
2920129
A/R
Lamp, Indicator
Ref.
PLATFORM BOX ASSEMBLY COMPONENTS
101 to 103
Not Used
104
0100048
A/R
Grease, Dielectric
105 to 138
Not Used
139
4460428
2
Connector, Strain Relief
140
Not Used
141
4460470
1
Nut, Terminal
142
4460471
1
Lockwasher, Terminal
143
Not Used
144
4460708
2
Connector, Female - 15 Position
145
4460905
5
Seal, Plug
146
Not Used
147
4922639
1
Harness, Platform Console Box (Includes Items 1-44)
148
4922666
1
Harness, Analyzer Cable
2/B
4460226
4
Socket, Female (Not Shown - Located at J2)
148A
4460761
1
Connector, Female - 4 Position
4460227
4
Pin, Male
149 to 151
Not Used
152
Not Available
1
Footswitch Harness
1060918
8ft/2.4m
Cable, Electrical - 18/3
152A
4460071
1
Connector, Strain Relief
