7-42 601S 3120747
SECTION 7 ELECTRICAL
Ref. OPTIONAL HARNESS COMPONENTS
801 0258075 Ref. AC (110Volt) to Platform Receptacle Components 1
801A 0860038 1 Box, Receptacle
3960422 1 Gasket
801B 4460346 1 110V GFI Receptacle
801C 4060700 1 Shield, Cover
801D 4460205 1 Plug, Male
801E 1060494 18in/47cm Cable, Electrical - 12/3
801F 4460071 1 Connector
802 0257887 1 Alarm/Harness Assembly
0140032 1 Alarm
2820035 6in/15cm Loom
802A 4460424 1 Plug
802B 4460268 2 Socket
802C 1 Relay Harness Options: (Not Shown)
4922123 Motion Alarm
4922124 Travel Alarm
803 Not Available 1 Strobe Light Harness
803A 4460320 1 Connector, Female - 2 Position
803B 4460267 2 Pin, Male
804 Ref Generator Electrical Components Options:
4933158 Ref Prior to S/N 64254 1
4933215 Ref S/N 64254 to S/N 85132 1
3990010 1 Diode - 6 Amp (Not Shown)
804A 1 Harness - On/Off Switch Options:
4922483 Prior to S/N 64254
4922641 S/N 64254 to S/N 85132
804B 4460320 1 Connector, Female - 2 Position
804C 4460267 2 Pin, Male
804D 4460424 1 Plug, Male - 2 Position
804E 4460268 2 Socket, Female
804F 4922482 1 Powermite Control Box to Relay
804G 4460027 1 110V GFI Receptacle
804H 4460190 1 110V GFI Receptacle
805 4921827 Ref. Generator to Rear of Boom Harness (110V) 1
Ref. Note: Harness used to connect AC at Platform Harness to
Generator Receptacle to power platform receptacle.
1060494 20ft/6.1m Cable, Electrical - 12/3
805A 4460205 1 Plug, Male (110V)
805B 4460134 1 Connector, Female (110V)
806 Not Available 1 Light Harness
3740049 1 Relay (Not Shown)
1060341 37ft/11.3m Cable, Electrical 16/2 (Does not Include terminals)
807 2920140 2 Platform Worklights Harness (Includes Light & Wire Only)
2820035 9ft/2.8m Loom, Vinyl
FIGURE 7-9. HARNESS COMPONENTS INSTALLATION (WITH ADE SYSTEM) (S/N 62137 TO
S/N 85132) (CONTINUED)
ITEM # PART NUMBER QTY. DESCRIPTION REV.
