7-38 601S 3120747
SECTION 7 ELECTRICAL
FIGURE 7-9. HARNESS COMPONENTS INSTALLATION (WITH ADE SYSTEM) (S/N 62137 TO
S/N 85132)
ITEM # PART NUMBER QTY. DESCRIPTION REV.
Ref. PLATFORM BOX HARNESS ASSEMBLIES
4922520 Ref. PRIOR TO S/N 64398 2/B
4922650 Ref. S/N 64398 TO S/N 67978 1/A
4922639 Ref. S/N 67978 TO S/N 85132 6/G
1 1 Harness, Console Box Options:
4922520 Prior to S/N 64398
4922650 S/N 64398 to S/N 67978
4922639 S/N 67978 to S/N 85132
2 to 15 Not Used
16 4460866 1 Terminal, 19 Pin Receptacle
17 4460874 1 Connector - 35 Position (Natural)
18 4460875 1 Connector - 35 Position (Gray)
19 4460873 1 Connector - 35 Position (Black)
20 4460871 A/R Socket, Female
21 4460464 7 Pin, Male (16 Gauge)
22 4460879 1 Terminal, Housing 2 Position
23 4460887 2 Terminal, (12 Gauge)
24 to 26 Not Used
27 4460418 4 Connector - 6 Position
28 4460419 12 Terminal, Female
29 4120035 A/R Base, Light
30 to 34 Not Used
35 4460508 3 Pin, Male (12 Gauge)
36 4460225 1 Plug, Male - 6 Position (S/N 67978 to S/N 85132)
37 4460227 5 Pin, Male (S/N 67978 to S/N 85132)
38 to 42 Not Used
43 4460434 2 Plug, Male - 15 Position (S/N 67978 to S/N 85132)
4460227 23 Pin, Male
44 2920129 A/R Lamp, Indicator (S/N 68642 to S/N 85132)
Ref. PLATFORM BOX ASSEMBLY COMPONENTS
101 4460428 2 Connector, Strain Relief
102 4460470 1 Nut, Conduit
103 4460471 1 Washer
104 1060330 1 Cable, Electrical - 16/3
105 4460071 1 Connector, Strain Relief
106 4460708 2 Receptacle - 15 Position
0270807 Ref. BOOM CABLES INSTALLATION 3
201 4922468 1 Harness, Main Boom
201A 1060896 67ft/20.4m Cable
201B 4460465 22 Socket, Female - #16
201C 4460865 1 Plug, Connector (19 Pin)
201D 4460509 8 Socket, Female - #12
201E 4460473 1 Clamp, Cable
