SECTION 6 - JLG CONTROL SYSTEM (ADE)
6-30
– JLG Lift –
3120866
9
(Jib)
0
1
2
No JIB installed.
JIB installed which has up and down movements only.
JIB installed which has up and down movements and side to side movements.
0
10
(4WS)
0
1
No Four-Wheel Steer installed.
Yes
0
11
(Soft Touch System)
0
1
No Soft Touch System Installed
Yes
0
12
(Generator/Welder)
0
1
2
No Generator Installed
Yes - 2500W or 7500W generator installed
Yes - Welder Installed
0
13
(Head and Tail Lights)
0
1
No Head and Tail Lights Installed
Yes
0
14
(Broken Cable
Switch Installed)
0
1
No Broken Cable Switch Installed
Yes
0
15
(Load Sensor)
0
1
2
3
No Load Sensor installed - (DOM - STD)
Functions in Creep, Overload Lamp Lit, Platform Alarm Beeps Continuously
All functions cutout, flash overload light (500mS on, 500mS off), Platform Alarm beeps (5
sec on, 55 sec off, 5 sec on) - (CE-STD)
Functions in Creep, Overload Lamp Lit, Platform Alarm beeps continuously, disable
upper telescope out and upper lift up
0
16
(Angle Sensor)
1
Digital Angle Sensor Installed
1
17
(Length Sensor)
1
Digital Length Sensor Installed
1
18
(Function
Cutout)
0
1
2
3
No Drive Cutout - (DOM - STD)
Boom function cutout while driving above elevation - (CE - STD)
Drive Cutout above elevation
Drive Cutout above elevation and tilted
0
19
(Ground Alarm)
0
1
2
3
No ground alarm installed.
Travel alarm- Sounds when the drive function is active. Option
Descent Alarm- Sounds when either lift down is active. Option
Motion alarm- Sounds when any function is active. Option
0
20
(Tower Prox Switches)
0
1
No Tower Prox Switches Installed
Tower Prox Switches Installed
450A, 510, 600A, 800A
0
21
(Flywheel Teeth)
0
1
133 Teeth (F3M Prior to 11-16-01; F4M1011 Prior to 1-1-02)
110 Teeth (Deutz 2011, F3M after 11-16-01; F4M1011 after 1-1-02
0
22
(Oscillating Axle)
0
1
No - Oscillating axle installed
Yes - Oscillating axle installed
0
4150364 - 6
Table 6-4. Machine Configuration Programming Information
Configuration Digit
Number
Description
Default Number
