SECTION 7 - ELECTRICAL
74
10MSP
3121229
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
504
4360572
1
Footswitch Harness (Includes Switch)
504A
4460424
1
Connector - 2 Position
504A
4460226
2
Socket, Female
505
4360573
1
Platform Gate Switch and Footswitch Harness
505A
4460320
2
Connector - 2 Position
505A
4460267
4
Pin, Male
506
See Note
1
Manual Descent (Lift Cylinder) Harness (Note: Not Available -
Purchase Replacement Coil - See CYLINDER SECTION for
Breakdown)
506A
4460424
1
Connector - 2 Position
506A
4460226
2
Socket, Female
507
4360515
1
Height Limiter Harness (Includes Switch)
507A
4460424
1
Connector - 2 Position
507A
4460226
2
Socket, Female
Ref
TOOLS (NOT SHOWN)
601
7002821
Ref
Crimper (For Wire to Pin/Socket Connections)
602
7002828
1
Stripper, Wire
606
7002842
1
Brake Crimp Removal Tool (Not Shown)
607
7002841
1
Motor Crimp Removal Tool (Not Shown)
608
7016618
1
Molex Tool (For Ground Control Station Electrical Connectors)
609
7002841
1
Intech Tool (For Drive Motor Electrical Connectors)
610
7002842
1
Intech Tool (For Drive Motor Brake Electrical Connectors)
611
7002847
1
Tyco/AMP Electronics Tool (For other General Electrical
Connectors)
612
7002848
1
Tyco/AMP Electronics Tool (For other General Electrical
Connectors)
